| Certificate | CE ISO9001 |
| Packing Details | Packing Size: 275mm* 275mm* 105mm 300mm*300mm*105mm Every spool product is strongly packed by carton box with antirust paper inside. Container load: 72boxes/pallet ,60boxes/pallet, 22Pallets/20ft |
| MOQ | 1 Pallet |
| Package | ||
| Specification | Wire Tray | Weight |
| Φ1.0~1.6mm | D100mm D200mm D270mm D300mm K300mm | 1kg, 5kg, 15kg, 17kg, 18kg, 20kg |
| TYPICAL CHEMICAL COMPOSITION | |||||
| C | Mn | Si | P | S | Al |
| 0.140 | 1.35 | 0.61 | 0.018 | 0.006 | 1.14 |
| Deposited Metal Mechanical Properties | ||
| Yield Strength σ0.2(Mpa) | Tensile Strength σb(Mpa) | Elongation δ5% |
| 504 | 576 | 24 |
| Diameter(mm) Parameters | 1.2mm | 1.6mm | ||
| Welding position | Flat | Vertical-up | Flat | Vertical-up |
| Voltage(Volt) | 30~36 | 25~26 | 30~45 | 26~30 |
| Current(Amp) | 250~330 | 150~220 | 300~450 | 160~250 |
| Stick out(mm) | 10~15 | 15~30 | ||
| Flow Rate(l/min) | 15~25 | 15~25 | ||
| Certificate | CE ISO9001 |
| Packing Details | Packing Size: 275mm* 275mm* 105mm 300mm*300mm*105mm Every spool product is strongly packed by carton box with antirust paper inside. Container load: 72boxes/pallet ,60boxes/pallet, 22Pallets/20ft |
| MOQ | 1 Pallet |
| Package | ||
| Specification | Wire Tray | Weight |
| Φ1.0~1.6mm | D100mm D200mm D270mm D300mm K300mm | 1kg, 5kg, 15kg, 17kg, 18kg, 20kg |
| TYPICAL CHEMICAL COMPOSITION | |||||
| C | Mn | Si | P | S | Al |
| 0.140 | 1.35 | 0.61 | 0.018 | 0.006 | 1.14 |
| Deposited Metal Mechanical Properties | ||
| Yield Strength σ0.2(Mpa) | Tensile Strength σb(Mpa) | Elongation δ5% |
| 504 | 576 | 24 |
| Diameter(mm) Parameters | 1.2mm | 1.6mm | ||
| Welding position | Flat | Vertical-up | Flat | Vertical-up |
| Voltage(Volt) | 30~36 | 25~26 | 30~45 | 26~30 |
| Current(Amp) | 250~330 | 150~220 | 300~450 | 160~250 |
| Stick out(mm) | 10~15 | 15~30 | ||
| Flow Rate(l/min) | 15~25 | 15~25 | ||
