Tungsten Electrodes

Ceriated Tungsten Electrodes
                                                                              ISO 6848
                                                              ANSI/AWS A5.12/A5.12M-98
Introduction:
Ceriated Tungsten is a non-radioactive material. It is known to be especially good for DC welding with low amperage because it starts very easily at low amps and usually requires about 10% less amps to operate than thoriated material.
Application:
It is very popular to be used for the welding of orbital tube, pipe, very small parts, short welding cycles and also where a specific number of welds are called and then the electrode is to be replaced.


Model	Oxide Additive		Impurities Content %	Tungsten Content %	Color Sign
	Type	Content %
WC20	CeO2	1.80-2.20	<0.20	Balance	Grey


Size:

Diameter		Diameter Tolerance	Length	Length Tolerance
mm	inch	mm	mm	mm
1.0	0.040	(+/-) 0.05	150, 175	(+/-) 0.10
1.6	1/16 (0.0625)	(+/-) 0.05	150, 175	(+/-) 0.10
2.0	5/64 (0.0781)	(+/-) 0.05	150, 175	(+/-) 0.10
2.4	3/32 (0.0938)	(+/-) 0.05	150, 175	(+/-) 0.10
3.2	1/8 (0.0125)	(+/-) 0.10	150, 175	(+/-) 0.10
4.0	5/32 (0.156)	(+/-) 0.10	150, 175	(+/-) 0.10
4.8	3/16 (0.187)	(+/-) 0.10	150, 175	(+/-) 0.10
6.4	1/4 (0.250)	(+/-) 0.10	150, 175	(+/-) 0.10


Recommended Welding Currents

Diameter of Electrode		Direct Current (A)		Alternative Current (A)
mm	inch	Straight Polarity	Reverse Polarity	Unbalanced Waves	Balanced Waves
1.0	0.040	15-80		10-80	20-60
1.6	1/16 (0.0625)	60-150	10-18	50-120	40-100
2.0	5/64 (0.0781)	100-200	12-20	70-160	60-130
2.4	3/32 (0.0938)	150-250	15-25	80-200	80-150
3.2	1/8 (0.0125)	220-350	20-35	150-270	120-200
4.0	5/32 (0.156)	350-500	35-50	220-350	170-260
4.8	3/16 (0.187)	420-650	45-65	240-420	220-340
6.4	1/4 (0.250)	600-900	65-100	350-560	250-450


Packing Details:
10 pieces / plastic box,10 boxes/carton, we also can do packing at customer’s requirements.




Zirconiated Tungsten Electrodes
                                                                              ISO 6848
                                                              ANSI/AWS A5.12/A5.12M-98                                                                                                                                            Introduction:
Zirconiated Tungsten has good performance in AC welding. It balls up well in AC welding and has a more stable arc than pure tungsten. Especially with excellent performance in high load AC welding, it is not replaceable by any other electrodes. It also resists contamination well in AC welding
Application:
. Zirconiated Tungsten is most commonly used for AC welding of aluminum and magnesium alloys.


Model	Oxide Additive		Impurities Content %	Tungsten Content %	Color Sign
	Type	Content %
WZ3	ZrO2	0.2-0.40	<0.20	Balance	Brown
WZ8	ZrO2	0.7-0.90	<0.20	Balance	White


Size:

Diameter		Diameter Tolerance	Length	Length Tolerance
mm	inch	mm	mm	mm
1.0	0.040	(+/-) 0.05	150, 175	(+/-) 0.10
1.6	1/16 (0.0625)	(+/-) 0.05	150, 175	(+/-) 0.10
2.0	5/64 (0.0781)	(+/-) 0.05	150, 175	(+/-) 0.10
2.4	3/32 (0.0938)	(+/-) 0.05	150, 175	(+/-) 0.10
3.2	1/8 (0.0125)	(+/-) 0.10	150, 175	(+/-) 0.10
4.0	5/32 (0.156)	(+/-) 0.10	150, 175	(+/-) 0.10
4.8	3/16 (0.187)	(+/-) 0.10	150, 175	(+/-) 0.10
6.4	1/4 (0.250)	(+/-) 0.10	150, 175	(+/-) 0.10


Recommended Welding Currents

Diameter of Electrode		Direct Current (A)		Alternative Current (A)
mm	inch	Straight Polarity	Reverse Polarity	Unbalanced Waves	Balanced Waves
1.0	0.040	15-80		10-80	20-60
1.6	1/16 (0.0625)	60-150	10-18	50-120	40-100
2.0	5/64 (0.0781)	100-200	12-20	70-160	60-130
2.4	3/32 (0.0938)	150-250	15-25	80-200	80-150
3.2	1/8 (0.0125)	220-350	20-35	150-270	120-200
4.0	5/32 (0.156)	350-500	35-50	220-350	170-260
4.8	3/16 (0.187)	420-650	45-65	240-420	220-340
6.4	1/4 (0.250)	600-900	65-100	350-560	250-450

Packing Details:
10 pieces / plastic box,10 boxes/carton, we also can do packing at customer’s requirements.
