| Chemical Composition | C | Mn | Si | S | P | Ni | Cr | Mo | V |
| Guarantee Value | -- | ≤1.60 | ≤0.75 | ≤0.035 | ≤0.040 | ≤0.30 | ≤0.20 | ≤0.30 | ≤0.08 |
| General Result | 0.077 | 1.07 | 0.54 | 0.005 | 0.014 | 0.011 | 0.028 | 0.007 | 0.016 |
| Test Item | Tensile Strength Rm (Mpa) | Yield Strength ReL(Mpa) | Elongation (%) | KV2 (J)-30ºC |
| Standard | ≥490 | ≥400 | ≥22 | ≥27 |
| Typical | 560 | 465 | 29 | 130 |
| Specification(mm) | Currents Range (A) | ||
| Diameter | Length | Flat | Vertical & Overhead |
| 2.0 | 300 | 40-60 | 30-55 |
| 2.5 | 300 | 60-100 | 60-80 |
| 3.2 | 350 | 80-140 | 80-100 |
| 4.0 | 400 | 150-200 | 140-170 |
| 5.0 | 400 | 160-230 | 150-210 |
