AWS:E2209-16

Model:
E2209-16
Brand:
Mighty

Quantity:



Inquire Add to Basket

Product Description

GB：E2209-16
AWS：E2209-16
Current：Used for welding ultra-low-carbon dual-phase stainless steel like 00Cr22Ni5Mo3N, SAF2205, etc.
Main Applications：

JQ.S2216

According with GB E2209-16
Corresponding with AWS E2209-16

Introduction: JQ.S2216 is a kind of ultra-low-carbon dual-phase stainless steel electrode with lime-titania type coating. The deposited metal contains 40%-50% ferrite. It has excellent mechanical properties and corrosion-resistance, especially reliable chloride corrosion-resistance and high pitting corrosion-resistance. It has excellent welding performance. AC/DC.

Uses: Used for welding ultra-low-carbon dual-phase stainless steel like 00Cr22Ni5Mo3N, SAF2205, etc.

Chemical Composition of Deposited Metal (%)

Chemical Composition	C	Mn	Si	S	P	Cu	Ni	Mo	Cr	N
Guarantee Value	≤0.04	0.50~2.0	≤0.90	≤0.03	≤0.04	≤0.75	8.5~10.5	2.5~3.5	21.5~23.5	0.08~0.20

Mechanical Properties of Deposited Metal

Test Item	R_m(MPa)	A(%)
Guarantee Value	≥690	≥20

Reference Current(AC, DC+)

Electrode Diameter(mm)	φ3.2
Welding Current (A)	90~120

Instructions:
1.The electrodes should be baked under about 250℃ for 1.5 hours before welding.
2.Direct current had better be used and the current should not be too strong.
