Home » Products » Welding electrodes for stainless steel » AWS:E410-16

Share to:

AWS:E410-16

Model:
E410-16
Brand:
Mighty

Quantity:



Inquire Add to Basket

Product Description

GB：E410-16
AWS：E410-16
Current：Used for welding 0Cr13 and 1Cr13 stainless steel structures, and also used for corrosion-resistant and wear-resistant surface overlaying.
Main Applications：

According with GB E410-16
Corresponding with AWS E410-16

Introduction: E410-16 is a kind of Cr13 stainless steel electrode with lime-titania type coating. AC/DC.

Uses: Used for welding 0Cr13 and 1Cr13 stainless steel structures, and also used for corrosion-resistant and wear-resistant surface overlaying.

Chemical Composition of Deposited Metal (%)

Chemical Composition	C	Mn	Si	S	P	Cu	Ni	Mo	Cr
Guarantee Value	≤0.12	≤1.00	≤0.90	≤0.030	≤0.040	≤0.75	≤0.70	≤0.75	11.0~13.5

Mechanical Properties of Deposited Metal(The temperature of the test pieces should be preserved under 730-760℃ for an hour, and then they should be cooled along with the furnace to 315℃ at a speed of not higher than 60℃/h, and finally cooled in the air.)

Test Item	R_m(MPa)	A(%)
Guarantee Value	≥450	≥20

Reference Current(AC, DC+)

Electrode Diameter(mm)	φ2.0	φ2.5	φ3.2	φ4.0	φ5.0
Welding Current (A)	40~80	50~100	70~130	100~160	140~200

Instructions:
1.The electrodes must be baked under about 150℃ for an hour before welding.
2.The weldments should be preheated to 250-350℃ before welding, and tempered under 700-730℃ after welding.
